MAG540W3 Specifications:
Audio & video
Video modes PAL, NTSC, 576p, 720p, 1080p, 1080i, 2160p (4K)
Audio codecs MPEG L1/L2/L3l, AAC-LC, HE AAC V1/V2, APE, FLAC, Dolby Digital Plus™
Video codecs MPEG1/2 MP@HL, MPEG4 part 2 (ASP), H.265 Main/Main 10@L5.1 High 2160p@60 fps (optional), H.264 AVC High@L5.1 2160p@30 fps, XviD, 3D video support
Video containers TS, AVI, MPEG, MP4, MOV, MKV, M2TS, VOB
Image formats JPEG, PNG, BMP, RAW
Subtitles DVB, PGS, SRT, SSA/ASS, SUB, teletext, WebVtt, closed captions
Playlist formats M3U, M3U8, PLS, CUE
Hardware
Chipset Amlogic S905Y4-B
Performance 16 500 DMIPS
Processor Quad-core ARM Cortex-A35, 2,000 MHz
RAM 1 GB LPDDR4
Flash memory 4 GB eMMC
Firmware and CAS/DRM
Operating system Linux 4.9
CAS/DRM Upon request
Middleware supported Pre-integrated Ministra TV platform. Image enhancement with operator apps, customization, or a full replacement is available.
Interfaces
Digital ports HDMI 2.1
Ethernet 100 Mbps
USB USB 2.0 × 2
Wi-Fi Built-in 2T2R ac (MAG540w3 only)
Power input
Power adapter DC 5V, 2A (DC 12V, 1А optional)
Dimensions
W/D/H 120 × 78 × 21 mm
Weight 110 g
